| Brand | NTN |
|---|---|
| Weight | 11.600000 |
| Product Category | Spherical Roller Bearings |
| Inner (mm) | 120 |
| Outer (mm) | 215 |
| Width (mm) | 76 |
| Seal | None, open bearing |
| Cage | Sheet steel cage |
23224EAW33-NTN
Product Category
Spherical Roller Bearings
SKU
400-10727
£656.27
Ships in 5-6 working days
·
2
pcs
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Clearance | CN - Standard radial clearance |
|---|---|
| Bore | Cylindrical bore |
| Material | Standard bearing steel |
| Outer Ring | Lubrication groove with lubrication holes on outer ring |
| Rings Material | Steel |
| Version | Standard version |
| Temperature Range | -30 to +200°C |
| Limit Speed (rpm) | 2800 |
| Reference Speed (rpm) | 2100 |
| Dyn. Load Rating (kn) | 857 |
| Stat. Load Rating (kn) | 998 |
| Fag/ina Part Number | 23224-E1-XL-TVPB |
| Nsk Part Number | 23224CE4 |
| Skf Part Number | 23224 CC/W33 |
| Tolerance Class | Tolerance class P0/PN2 / ABEC 1 |
| Iso | ISO 15 |
