| Brand | NTN |
|---|---|
| Weight | 0.470000 |
| Product Category | Deep groove ball bearings |
| Inner (mm) | 50 |
| Outer (mm) | 90 |
| Width (mm) | 20 |
| Seal | Non-contact seal on both sides |
| Cage | Sheet steel cage |
6210LLBCM/5K-NTN
Product Category
Deep groove ball bearings
SKU
400-00526
£32.71
Ships in 5-6 working days
·
11
pcs
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Clearance | CN - Standard radial clearance with reduced tolererances |
|---|---|
| Bore | Cylindrical bore |
| Material | Standard bearing steel |
| Outer Ring | Without flange/groove |
| Ball Rows | Single row bearing |
| Rings Material | Steel |
| Material Of Rolling Elements | Standard bearing steel |
| Temperature Range | -40 to +120°C |
| Current Insulation | No current insulation |
| Limit Speed Grease (rpm) | 7100 |
| Dyn. Load Rating (kn) | 39 |
| Stat. Load Rating (kn) | 23 |
| Greasing | High temperature grease |
| Fag/ina Part Number | 6210-C-2BRS |
| Nsk Part Number | 6210VV |
| Skf Part Number | 6210-2RZ |
| Suffix Description | LLB - Non-contact seal on both sides |
| Tolerance Class | Tolerance class P0/PN2 / ABEC 1 |
| Iso | ISO 15 |
