| Brand | NTN |
|---|---|
| Weight | 3.050000 |
| Product Category | Deep groove ball bearings |
| Inner (mm) | 75 |
| Outer (mm) | 160 |
| Width (mm) | 37 |
| Seal | Contact seals on both sides |
| Cage | Sheet steel cage |
6315LLUC3/5K-NTN
Product Category
Deep groove ball bearings
SKU
400-05457
£158.38
ships tomorrow
·
1
pc
Ships in 5-6 working days
·
10
pcs
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Clearance | C3 - Slightly increased radial clearance |
|---|---|
| Bore | Cylindrical bore |
| Material | Standard bearing steel |
| Outer Ring | Without flange/groove |
| Ball Rows | Single row bearing |
| Rings Material | Steel |
| Material Of Rolling Elements | Standard bearing steel |
| Temperature Range | -25 to +110°C |
| Current Insulation | No current insulation |
| Limit Speed Grease (rpm) | 2900 |
| Dyn. Load Rating (kn) | 126 |
| Stat. Load Rating (kn) | 77 |
| Greasing | High temperature grease |
| Fag/ina Part Number | 6315-2RSR-C3 |
| Nsk Part Number | 6315DDUC3 |
| Skf Part Number | 6315-2RS1/C3 |
| Suffix Description | LLU - Contact seals on both sides |
| Tolerance Class | Tolerance class P0/PN2 / ABEC 1 |
| Iso | ISO 15 |
