| Brand | NTN |
|---|---|
| Weight | 0.050000 |
| Product Category | High Precision Ball Bearings (Spindle bearings) |
| Inner (mm) | 25 |
| Outer (mm) | 42 |
| Width (mm) | 9 |
| Seal | None, open bearing |
| Cage | Polyamide cage |
7905UCG/GNP42-NTN
Product Category
High Precision Ball Bearings (Spindle bearings)
SKU
400-03467
Out of stock
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Clearance | CN - Standard radial clearance |
|---|---|
| Bore | Cylindrical bore |
| Material | Standard bearing steel |
| Rings Material | Steel |
| Material Of Rolling Elements | Standard bearing steel |
| Temperature Range | -30 to +100°C |
| Arrangement | Single universal bearing |
| Preload | Normal preload |
| Contact Angle | 15 degree |
| Lubrication | Preserved |
| Lubrication Hole | Without lubrication groove |
| Limit Speed Oil (rpm) | 56000 |
| Limit Speed Grease (rpm) | 35000 |
| Dyn. Load Rating (kn) | 9.05 |
| Stat. Load Rating (kn) | 6 |
| Fag/ina Part Number | B71905CTP4SUL |
| Nsk Part Number | 7905CTRSULP3 |
| Skf Part Number | 71905CDGB/P4A |
| Tolerance Class | Dimensional accuracy P4 or ABEC 7, running accuracy P2 or AB |
| Iso | ISO 15 |
