| Brand | NTN |
|---|---|
| Weight | 1.120000 |
| Product Category | Cylindrical roller bearings |
| Inner (mm) | 60 |
| Outer (mm) | 110 |
| Width (mm) | 28 |
| Seal | None, open bearing |
| Cage | Polyamide cage |
NUP2212EAT2XU-NTN
Product Category
Cylindrical roller bearings
SKU
400-07271
Out of stock
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Clearance | CN - Standard radial clearance |
|---|---|
| Bore | Cylindrical bore |
| Rings Material | Steel |
| Limit Speed Oil (rpm) | 7300 |
| Limit Speed Grease (rpm) | 5200 |
| Dyn. Load Rating (kn) | 155 |
| Stat. Load Rating (kn) | 157 |
| Fag/ina Part Number | NUP 2212-E-XL-TVP2 |
| Skf Part Number | NUP 2212 ECP |
| Iso | ISO 15 |
